Display Technology 0.61" SXRD

Native Resolution 1920 x 1080 (Total 2,073,600 pixels)

Brightness 1000 lumens; D65 Mode: 800 lumens

Contrast Ratio 150,000 : 1 (on/off) with Diamond Black IRIS Operation

Zoom/Focus Motorized Zoom & Focus (Zoom Ratio 1.8:1)

Throw Distance 1.6 – 2.8 x Screen Width of 16:9 screen (Approx)

Powered Lens Shift Range Vertical: +/-100%; Horizontal: +/-45%

Image Size 50” - 200”

Source Lamp 230W Standard Mode; 190W Low Mode with lamp life up to 4000 hours.

Video Compatibility NTSC / NTSC 4.43 / PAL / SECAM

Component Video: 480i, 480p, 576i 576p, 720p, 1080i, 1080p

PC Compatibility Resolution: VGA (640 x 480) @60Hz - WUXGA (1920 x 1200) @60Hz

Input Terminals HDMI, Ver 1.4a (3D) Deep Color x 2

Component (RCA x3) x1; S-VIDEO (4pin) x 1; Video: Composite x 1

PC: Mini D-Sub 15pin x 1

Communication Terminal RS-232C (IN): D-Sub 9pin, male) x 1

Other Features 3D Capability with Optional Emitter & 3D glasses

Extra Low Dispersion All-Glass Lens

240 Hz drive (3D)

Gamma correction (cinema / 2.0 / 2.1 / user) ; Cinema Filter (Movie/Brightness)

Color Matching (R/G/B/C/M/Y)

Pixel Adjust (Horiz R/G/B, VertR/G/B)

Digital keystone-correction: Vertical ±40°; Horizontal ±25°

Noise Reduction (TNR/MNR/BAR) & Detail Enhancement

10 languages OSD

3D Y/C digital comb filter and 3D noise reduction

Video Line Doubler: 2:3 / 2:2 pull-down

Rear-access Lamp

Illuminated Full-Function IR Remote

Power Requirements AC 100 - 240 V, 50 / 60 Hz

Power Consumption Operating 330W / 3.3A

Dimensions (W x H x D) 480 mm x 195 mm x 520 mm / 18.9” x 7.7” x 20.5”

Fan Noise Whisper Quiet 22 dBA (Low Mode)

Weight 33 lbs.
